A Chartwell property with separated buildings or equipment needs a simple destination map, while actual cable routes and supply relationships remain for the electrician to establish.
Mark the destinations
Draw the main building, outbuildings, pumps, gates and known boards. Note what has power and what does not, without drawing assumed underground routes as fact.
- Buildings, equipment and known boards
- Affected and unaffected destinations
- Keys, outdoor access and authorised contact
Arrange full access
Identify keys, occupants, animals and outdoor conditions that affect safe access. Do not enter confined, wet or visibly damaged electrical areas to complete the map.
Request a usable record
Ask the electrician to state which supplies and circuits were traced, what remained inaccessible and what repair or further investigation is proposed. Keep the map with later changes.
Useful questions
Questions property owners ask next.
Must a Chartwell property map show exact electrical cable routes?+
No. A location map is useful even when routes are unknown. Mark destinations and known equipment, and let the electrician establish the electrical relationships safely.
